NXC CLI Reference Guide
233
CHAPTER 37
Session Timeout
Use these commands to modify and display the session timeout values. You must use the
configure terminal command before you can use these commands.
The following example sets the UDP session connect timeout to 10 seconds, the UDP deliver
session timeout to 15 seconds, and the ICMP timeout to 15 seconds.
Table 129 Session Timeout Commands
COMMAND DESCRIPTION
session timeout {udp-connect <1..300> | udp-
deliver <1..300> | icmp <1..300>}
Sets the timeout for UDP sessions to connect or
deliver and for ICMP sessions.
session timeout { tcp-close <1..300> | tcp-
closewait <1..300> | tcp-established
<1..432000> | tcp-finwait <1..300> | tcp-
lastack <1..300> | tcp-synrecv <1..300> | tcp-
synsent <1..300> | tcp-timewait <1..300> }
Sets the timeout for TCP sessions in the
ESTABLISHED, SYN_RECV, FIN_WAIT,
SYN_SENT, CLOSE_WAIT, LAST_ACK, or
TIME_WAIT state.
show session timeout {icmp | tcp | udp} Displays ICMP, TCP, and UDP session timeouts.
Router(config)# session timeout udp-connect 10
Router(config)# session timeout udp-deliver 15
Router(config)# session timeout icmp 15
Router(config)# show session timeout udp
UDP session connect timeout: 10 seconds
UDP session deliver timeout: 15 seconds
Router(config)# show session timeout icmp
ICMP session timeout: 15 seconds
