Chapter 9 AP Group
NXC CLI Reference Guide
85
The following example shows the settings and status of the VLAN(s) configured for the
managed APs (NWA5301-NJ) in the default AP group.
The following example shows the status of Ethernet ports for the managed APs (NWA5301-
NJ) in the default AP group. It also shows whether the lan1 port is enabled and what the port’s
VLAN ID is.
Router(config)# show ap-group-profile default lan-provision model nwa5301-nj
interface vlan
No. Name Active VID Member
===========================================================================
1 vlan0 yes 1 lan1,lan2,lan3
Router(config)# show ap-group-profile default lan-provision model nwa5301-nj
interface vlan0
active: yes
interface name: vlan0
VID: 1
member: lan1&lan2&lan3
lan1_tag: untag
lan2_tag: untag
lan3_tag: untag
Router(config)#
Router(config)# show ap-group-profile default lan-provision model nwa5301-nj
interface ethernet
No. Name Active PVID
===========================================================================
1 uplink yes n/a
2 lan1 yes 1
3 lan2 yes 1
4 lan3 yes 1
Router(config)# show ap-group-profile default lan-provision model nwa5301-nj
interface lan1
Name Active PVID
===========================================================================
lan1 yes 1
Router(config)#
