Chapter 10 Wireless LAN Profiles
NXC CLI Reference Guide
96
The following table describes the commands available for security profile management. You
must use the
configure terminal command to enter the configuration mode before you
can use these commands.
Table 37 Command Summary: Security Profile
COMMAND DESCRIPTION
show wlan-security-profile {all |
security_profile_name}
Displays the security profile(s).
all: Displays all profiles for the selected operating mode.
security_profile_name: Displays the specified
profile for the selected operating mode.
wlan-security-profile rename
security_profile_name1
security_profile_name2
Gives existing security profile
(security_profile_name1) a new name,
(security_profile_name2).
[no] wlan-security-profile
security_profile_name
Enters configuration mode for the specified security
profile. Use the no parameter to remove the specified
profile.
description description Sets the description for the profile. You may use up to 60
alphanumeric characters, underscores (_), or dashes (-).
This value is case-sensitive
[no] dot1x-eap Enables 802.1x secure authentication. Use the no
parameter to disable it.
[no] dot11w Data frames in 802.11 WLANs can be encrypted and
authenticated with WEP, WPA or WPA2. But 802.11
management frames, such as beacon/probe response,
association request, association response, de-
authentication and disassociation are always
unauthenticated and unencrypted. IEEE 802.11w
Protected Management Frames allows APs to use the
existing security mechanisms (encryption and
authentication methods defined in IEEE 802.11i WPA/
WPA2) to protect management frames. This helps
prevent wireless DoS attacks.
Enables management frame protection (MFP) to add
security to 802.11 management frames. Use the no
parameter to disable it.
dot11w-op <1..2> Sets whether wireless clients have to support
management frame protection in order to access the
wireless network.
1: if you do not require the wireless clients to support
MFP. Management frames will be encrypted if the clients
support MFP.
2: wireless clients must support MFP in order to join the
AP’s wireless network.
eap {external | internal auth_method} Sets the 802.1x authentication method.
group-key <30..30000> Sets the interval (in seconds) at which the AP updates the
group WPA/WPA2 encryption key.
The default is 3000.
idle <30..30000> Sets the idle interval (in seconds) that a client can be idle
before authentication is discontinued.
The default is 300.
