Chapter 1 Command Line Interface
NXC CLI Reference Guide
22
1.4.3 Command Summary
This section lists the commands for the feature in one or more tables.
1.4.4 Command Examples
This section contains any examples for the commands in this feature.
1.4.5 Command Syntax
The following conventions are used in this guide.
• A command or keyword in courier new must be entered literally as shown. Do not
abbreviate.
• Values that you need to provide are in italics.
• Required fields that have multiple choices are enclosed in curly brackets
{}.
• A range of numbers is enclosed in angle brackets
<>.
• Optional fields are enclosed in square brackets
[].
•The
| symbol means OR.
For example, look at the following command to create a TCP/UDP service object.
service-object object-name {tcp | udp} {eq <1..65535> | range <1..65535>
<1..65535>}
1 Enter service-object exactly as it appears.
2 Enter the name of the object where you see object-name.
3 Enter
tcp or udp, depending on the service object you want to create.
4 Finally, do one of the following.
•Enter
eq exactly as it appears, followed by a number between 1 and 65535.
•Enter
range exactly as it appears, followed by two numbers between 1 and 65535.
1.4.6 Changing the Password
It is highly recommended that you change the password for accessing the NXC. See Section
22.2 on page 144 for the appropriate commands.
1.5 CLI Modes
You run CLI commands in one of several modes.
Table 3 CLI Modes
USER PRIVILEGE CONFIGURATION SUB-COMMAND
What Guest users
can do
Unable to access Unable to access Unable to access Unable to access
What User users
can do
• Look at (but not
run) available
commands
Unable to access Unable to access Unable to access
