Zyxel NXC2500 [37/275] Status
![Zyxel NXC2500 [37/275] Status](/views2/1169008/page37/bg25.png)
NXC CLI Reference Guide
37
CHAPTER 4
Status
This chapter explains some commands you can use to display information about the NXC’s
current operational state.
4.1 Status Show Commands
The following table describes the commands available for NXC system status.
Table 8 Status Show Commands
COMMAND DESCRIPTION
show boot status Displays details about the NXC’s startup state.
show comport status Displays whether the console and auxiliary ports are on or off.
show cpu status Displays the CPU utilization.
show disk Displays the disk utilization.
show extension-slot Displays the status of the extension card slot and the USB ports and the names of
any connected devices.
show fan-speed Displays the current fan speed.
show led status Displays the status of each LED on the NXC.
show mac Displays the NXC’s MAC address.
show mem status Displays what percentage of the NXC’s memory is currently being used.
show ram-size Displays the size of the NXC’s on-board RAM.
show serial-number Displays the serial number of this NXC.
show socket listen Displays the NXC’s listening ports.
show socket open Displays the ports that are open on the NXC.
show system uptime Displays how long the NXC has been running since it last restarted or was turned
on.
show version Displays the NXC’s model, firmware and build information.
