Zyxel NXC2500 [71/275] Learned routing information commands
![Zyxel NXC2500 [71/275] Learned routing information commands](/views2/1169008/page71/bg47.png)
Chapter 7 Route
NXC CLI Reference Guide
71
7.5 Learned Routing Information Commands
This table lists the commands to look at learned routing information.
7.5.1 show ip route Command Example
The following example shows learned routing information on the NXC.
Table 27 ip route Commands: Learned Routing Information
COMMAND DESCRIPTION
show ip route [kernel | connected | static] Displays learned routing and other routing information.
Router> show ip route
Flags: A - Activated route, S - Static route, C - directly Connected
O - OSPF derived, R - RIP derived, G - selected Gateway
! - reject, B - Black hole, L - Loop
IP Address/Netmask Gateway IFace Metric Flags
Persist
===========================================================================
127.0.0.0/8 0.0.0.0 lo 0 ACG -
192.168.1.0/24 0.0.0.0 vlan0 0 ACG -
Router>
