Chapter 8 AP Management
NXC CLI Reference Guide
77
show capwap ap fallback Displays whether the managed AP(s) will change back to
associate with the primary AP controller when the primary
AP controller is available.
show capwap ap fallback interval Displays the interval for how often the managed AP(s)
check whether the primary AP controller is available.
show capwap ap wait-list Displays a list of connected but as-of-yet unmanaged
APs. This is known as the ‘wait list’.
show capwap manual-add Displays the current manual add option.
show capwap station all Displays information for all stations connected to the APs
on the management list.
show country-code list Displays a reference list of two-letter country codes.
show default country-code Displays the default country code configured on the NXC.
show lan-provision ap ap_mac interface
{lan_port | vlan_interface | all| ethernet
| uplink | vlan}
Displays the port and/or VLAN settings for the specified
AP.
You can also set to display settings for a specified port, a
sepcified VLAN, all physical Ethernet ports, the uplink
port or all VLANs on the AP.
Table 29 Command Summary: AP Management (continued)
COMMAND DESCRIPTION
