IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
This is a Reference Guide for a series of products intended for people who want to configure the NXC
via Command Line Interface (CLI).
Some commands or command options in this guide may not be available in your
product. See your product's User’s Guide for a list of supported features. Every effort
has been made to ensure that the information in this guide is accurate.
How To Use This Guide
1 Read Chapter 1 on page 15 for how to access and use the CLI (Command Line Interface).
2 Read Chapter 2 on page 31 to learn about the CLI user and privilege modes.
Do not use commands not documented in this guide.
Related Documentation
• Quick Start Guide
The Quick Start Guide shows how to connect the NXC and access the Web Configurator.
• User’s Guide
The User’s Guide explains how to use the Web Configurator to configure the NXC.
It is recommended you use the Web Configurator to configure the NXC.
