Chapter 11 Rogue AP
NXC CLI Reference Guide
106
11.2.1 Rogue AP Detection Examples
This example sets the device associated with MAC address 00:13:49:11:11:11 as a rogue AP,
and the device associated with MAC address 00:13:49:11:11:22 as a friendly AP. It then
removes MAC address from the rogue AP list with the assumption that it was misidentified.
This example displays the rogue AP detection list.
rogue-ap ap_mac description2 Sets the device that owns the specified MAC address as
a rogue AP. You can also assign a description to this
entry on the rogue AP list.
no rogue-ap ap_mac Removes the device that owns the specified MAC
address from the rogue AP list.
friendly-ap ap_mac description2 Sets the device that owns the specified MAC address as
a friendly AP. You can also assign a description to this
entry on the friendly AP list.
no friendly-ap ap_mac Removes the device that owns the specified MAC
address from the friendly AP list.
exit Exits configuration mode for rogue AP detection.
show rogue-ap detection monitoring Displays a table of detected APs and information about
them, such as their MAC addresses, when they were last
seen, and their SSIDs, to name a few.
show rogue-ap detection list {rogue |
friendly| all}
Displays the specified rogue/friendly/all AP list.
show rogue-ap detection status Displays whether rogue AP detection is on or off.
show rogue-ap detection info Displays a summary of the number of detected devices
from the following categories: rogue, friendly, ad-hoc,
unclassified, and total.
Table 45 Command Summary: Rogue AP Detection (continued)
COMMAND DESCRIPTION
Router(config)# rogue-ap detection
Router(config-detection)# rogue-ap 00:13:49:11:11:11 rogue
Router(config-detection)# friendly-ap 00:13:49:11:11:22 friendly
Router(config-detection)# no rogue-ap 00:13:49:11:11:11
Router(config-detection)# exit
Router(config)# show rogue-ap detection list rogue
no. mac description
contain
===========================================================================
1 00:13:49:18:15:5A
0
