Zyxel NXC2500 [175/275] Enc agent command examples
![Zyxel NXC2500 [175/275] Enc agent command examples](/views2/1169008/page175/bgaf.png)
Chapter 29 ENC
NXC CLI Reference Guide
175
29.2.1 ENC-Agent Command Examples
The following example shows you how to turn on the ENC agent feature on the NXC and sets
the ENC server’s IP address. This example also enables HTTPS authentication and shows you
the ENC agent settings.
no enc-agent periodic-
inform
Sets the NXC to not periodically send “Inform” messages to the
ENC or ACS server.
[no] debug enc-agent
activate
Enables ENC-agent debug logging. The no command disables
ENC-agent debug logging.
[no] debug enc-agent stderr Shows ENC-agent debug messages on the console. The no
command sets the NXC to not ENC-agent debug messages on
the console.
show enc-agent
configuration
Displays the NXC’s ENC agent settings.
Table 92 Command Summary: ENC-Agent (continued)
COMMAND DESCRIPTION
Router# configure terminal
Router(config)# enc-agent activate
Router(config)# enc-agent manager https://172.16.1.10:8443/enc/TR069
Router(config)# enc-agent server certificate enc.cer
Doing /var/zyxel/cert/https_trusted/
enc.cer.pem => 3eed352e.0
https_my_default_cert.pem => 470d99db.0
Router(config)# enc-agent authentication enable
Router(config)# show enc-agent configuration
Activate: YES
ACS URL: https://172.16.1.10:8443/enc/TR069
ACS Username:
ACS Password:
Username:
Password:
Provisioning Code:
Server Type: TR069 ACS
Keepalive: ENABLE
Keepalive Interval: 20
Periodic Inform: DISABLE
Periodic Inform Interval: 3600
Custom IP: NO
HTTPS Authentication: YES
Server Certificate: enc.cer
Router(config)#
