Chapter 30 Certificates
NXC CLI Reference Guide
178
30.4 Certificates Commands Summary
The following table lists the commands that you can use to display and manage the NXC’s
summary list of certificates and certification requests. You can also create certificates or
certification requests. Use the
configure terminal command to enter the configuration
mode to be able to use these commands.
organizational_unit Identify the organizational unit or department to which the certificate
owner belongs. You can use up to 31 characters. You can use
alphanumeric characters, the hyphen and the underscore.
organization Identify the company or group to which the certificate owner belongs. You
can use up to 31 characters. You can use alphanumeric characters, the
hyphen and the underscore.
country Identify the nation where the certificate owner is located. You can use up
to 31 characters. You can use alphanumeric characters, the hyphen and
the underscore.
key_length Type a number to determine how many bits the key should use (512 to
2048). The longer the key, the more secure it is. A longer key also uses
more PKI storage space.
password When you have the NXC enroll for a certificate immediately online, the
certification authority may want you to include a key (password) to
identify your certification request. Use up to 31 of the following
characters. a-zA-Z0-9;|`~!@#$%^&*()_+\{}':,./<>=-
ca_name When you have the NXC enroll for a certificate immediately online, you
must have the certification authority’s certificate already imported as a
trusted certificate. Specify the name of the certification authority’s
certificate. It can be up to 31 alphanumeric and ;‘~!@#$%^&()_+[]{}’,.=-
characters.
url When you have the NXC enroll for a certificate immediately online, enter
the IP address (or URL) of the certification authority server. You can use
up to 511 of the following characters. a-zA-Z0-9'()+,/:.=?;!*#@$_%-
Table 93 Certificates Commands Input Values (continued)
LABEL DESCRIPTION
Table 94 ca Commands Summary
COMMAND DESCRIPTION
ca enroll cmp name certificate_name cn-type
{ip cn cn_address|fqdn cn cn_domain_name|mail
cn cn_email} [ou organizational_unit] [o
organization] [c country] [usr-def
certificate_name] key-type {rsa|dsa} key-len
key_length num <0..99999999> password password
ca ca_name url url;
Enrolls a certificate with a CA using Certificate
Management Protocol (CMP). The certification
authority may want you to include a reference
number and key (password) to identify your
certification request.
ca enroll scep name certificate_name cn-type
{ip cn cn_address|fqdn cn cn_domain_name|mail
cn cn_email} [ou organizational_unit] [o
organization] [c country] [usr-def
certificate_name] key-type {rsa|dsa} key-len
key_length password password ca ca_name url
url
Enrolls a certificate with a CA using Simple
Certificate Enrollment Protocol (SCEP). The
certification authority may want you to include a
key (password) to identify your certification
request.
