Chapter 32 System Remote Management
NXC CLI Reference Guide
195
32.8.3 SNMP Commands
The following table describes the commands available for SNMP. You must use the
configure terminal command to enter the configuration mode before you can use these
commands.
Table 107 Command Summary: SNMP
COMMAND DESCRIPTION
[no] snmp-server Allows SNMP access to the NXC. The no
command disables SNMP access to the NXC.
[no] snmp-server community community_string
{ro|rw}
Enters up to 64 characters to set the password
for read-only (ro) or read-write (rw) access. The
no command resets the password for read-only
(
ro) or read-write (rw) access to the default.
[no] snmp-server contact description Sets the contact information (of up to 60
characters) for the person in charge of the NXC.
The no command removes the contact
information for the person in charge of the NXC.
[no] snmp-server enable {informs|traps} Enables all SNMP notifications (informs or traps).
The
no command disables all SNMP
notifications (informs or traps).
[no] snmp-server host {fqdn | ipv4_address}
[community_string]
Sets the IP address or domain name of the host
that receives the SNMP notifications. The
no
command removes the host that receives the
SNMP notifications.
[no] snmp-server location description Sets the geographic location (of up to 60
characters) for the NXC. The
no command
removes the geographic location for the NXC.
[no] snmp-server port <1..65535> Sets the SNMP service port number. The
no
command resets the SNMP service port number
to the factory default (161).
snmp-server rule {rule_number|append|insert
rule_number} access-group {ALL|address_object}
zone {ALL|zone_object} action {accept|deny}
Sets a service control rule for SNMP service.
address_object: The name of the IP address
(group) object. You may use 1-31 alphanumeric
characters, underscores(
_), or dashes (-), but the
first character cannot be a number. This value is
case-sensitive.
zone_object: The name of the zone. Use up to
31 characters (a-zA-Z0-9_-). The name cannot
start with a number. This value is case-sensitive.
You can also use pre-defined zone names like
LAN and WLAN.
snmp-server rule move rule_number to rule_number Changes the index number of a service control
rule.
no snmp-server rule rule_number Deletes a service control rule for SNMP service.
[no] snmp-server version {v2c|v3} Sets the SNMP version to use for communication
with the SNMP manager. The
no command does
not allow SNMP managers using the specified
SNMP version to access the NXC.
[no] snmp-server v3user username username
authentication {md5|sha} privacy {aes|des|none}
privilege {ro|rw}
Sets the SNMPv3 user account and its privilege
of read-only (ro) or read-write (rw) access.
The
no command removes the SNMPv3 user
account.
