![Zyxel NXC2500 [93/275] Ssid profile commands](/views2/1169008/page93/bg5d.png)
Chapter 10 Wireless LAN Profiles
NXC CLI Reference Guide
93
• block acknowledgement enabled
• a short guard interval
• an output power of 100%
It will also assign the SSID profile labeled ‘default’ in order to create WLAN VAP (wlan-1-1)
functionality within the radio profile.
10.3 SSID Profile Commands
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
Router(config)# wlan-radio-profile RADIO01
Router(config-profile-radio)# activate
Router(config-profile-radio)# band 2.4G band-mode bgn
Router(config-profile-radio)# 2g-channel 6
Router(config-profile-radio)# ch-width 20/40
Router(config-profile-radio)# dtim-period 2
Router(config-profile-radio)# beacon-interval 100
Router(config-profile-radio)# ampdu
Router(config-profile-radio)# limit-ampdu 65535
Router(config-profile-radio)# subframe-ampdu 64
Router(config-profile-radio)# amsdu
Router(config-profile-radio)# limit-amsdu 4096
Router(config-profile-radio)# block-ack
Router(config-profile-radio)# guard-interval short
Router(config-profile-radio)# tx-mask 5
Router(config-profile-radio)# rx-mask 7
Router(config-profile-radio)# output-power 21dBm
Router(config-profile-radio)# ssid-profile 1 default
Table 34 Input Values for General SSID Profile Commands
LABEL DESCRIPTION
ssid_profile_name The SSID profile name. You may use 1-31 alphanumeric characters,
underscores (
_), or dashes (-), but the first character cannot be a
number. This value is case-sensitive.
ssid The SSID broadcast name. You may use 1-32 alphanumeric
characters, underscores (_), or dashes (-). This value is case-sensitive.
wlan_qos Sets the type of QoS the SSID should use.
disable: Turns off QoS for this SSID.
wmm: Turns on QoS for this SSID. It automatically assigns Access
Categories to packets as the device inspects them in transit.
wmm_be: Assigns the “best effort” Access Category to all traffic moving
through the SSID regardless of origin.
wmm_bk: Assigns the “background” Access Category to all traffic
moving through the SSID regardless of origin.
wmm_vi: Assigns the “video” Access Category to all traffic moving
through the SSID regardless of origin.
wmm_vo: Assigns the “voice” Access Category to all traffic moving
through the SSID regardless of origin.
vlan_iface The VLAN interface name of the controller (in this case, it is NXC5200).
The maximum VLAN interface number is product-specific; for the NXC,
the number is 512.
