NXC CLI Reference Guide
201
CHAPTER 34
File Manager
This chapter covers how to work with the NXC’s firmware, certificates, configuration files,
custom IDP signatures, packet trace results, shell scripts and temporary files.
34.1 File Directories
The NXC stores files in the following directories.
34.2 Configuration Files and Shell Scripts Overview
You can store multiple configuration files and shell script files on the NXC.
When you apply a configuration file, the NXC uses the factory default settings for any features
that the configuration file does not include. Shell scripts are files of commands that you can
store on the NXC and run when you need them. When you run a shell script, the NXC only
applies the commands that it contains. Other settings do not change.
You can edit configuration files or shell scripts in a text editor and upload them to the NXC.
Configuration files use a .conf extension and shell scripts use a .zysh extension.
Table 112 FTP File Transfer Notes
DIRECTORY FILE TYPE
FILE NAME
EXTENSION
A
A. After you log in through FTP, you do not need to change directories in order to upload the firmware.
Firmware (upload only) bin
cert Non-PKCS#12 certificates cer
conf Configuration files conf
idp IDP custom signatures rules
packet_trace Packet trace results (download only)
script Shell scripts .zysh
tmp Temporary system maintenance files and crash dumps for
technical support use (download only)
