Chapter 6 Interfaces
NXC CLI Reference Guide
52
6.2.2 DHCP Setting Commands
This table lists DHCP setting commands. DHCP is based on DHCP pools. Create a DHCP
pool if you want to assign a static IP address to a MAC address or if you want to specify the
starting IP address and pool size of a range of IP addresses that can be assigned to DHCP
clients. There are different commands for each configuration. Afterwards, in either case, you
have to bind the DHCP pool to the interface.
Table 14 interface Commands: DHCP Settings
COMMAND DESCRIPTION
show ip dhcp dhcp-options Shows the DHCP extended option settings.
show ip dhcp pool [profile_name] Shows information about the specified DHCP pool
or about all DHCP pools.
ip dhcp pool rename profile_name profile_name Renames the specified DHCP pool from the first
profile_name to the second profile_name.
[no] ip dhcp pool profile_name Creates a DHCP pool if necessary and enters sub-
command mode. You can use the DHCP pool to
create a static entry or to set up a range of IP
addresses to assign dynamically.
About the sub-command settings:
• If you use the
host command, the NXC treats
this DHCP pool as a static DHCP entry.
• If you do not use the
host command and use
the network command, the NXC treats this
DHCP pool as a pool of IP addresses.
• If you do not use the
host command or the
network command, the DHCP pool is not
properly configured and cannot be bound to
any interface.
The no command removes the specified DHCP
pool.
show Shows information about the specified DHCP pool.
Use the following commands if you want to create
a static DHCP entry. If you do not use the
host
command, the commands that are not in this
section have no effect, but you can still set them.
[no] host ip Specifies the static IP address the NXC should
assign. Use this command, along with
hardware-address, to create a static DHCP
entry.
Note: The IP address must be in the
same subnet as the interface to
which you plan to bind the DHCP
pool.
When this command is used, the NXC treats this
DHCP pool like a static entry, regardless of the
network setting. The no command clears this
field.
[no] hardware-address mac_address Reserves the DHCP pool for the specified MAC
address. Use this command, along with host, to
create a static DHCP entry. The
no command
clears this field.
