Chapter 36 Reports and Reboot
NXC CLI Reference Guide
231
36.2.1 Email Daily Report Example
This example sets the NXC to send a daily report e-mail.
Router(config)# daily-report
Router(config-daily-report)# smtp-address example-SMTP-mail-server.com
Router(config-daily-report)# mail-subject set test subject
Router(config-daily-report)# no mail-subject append system-name
Router(config-daily-report)# mail-subject append date-time
Router(config-daily-report)# mail-from my-email@example.com
Router(config-daily-report)# example-administrator@example.com
Router(config-daily-report)# no mail-to-2
Router(config-daily-report)# no mail-to-3
Router(config-daily-report)# mail-to-4 my-email@example.com
Router(config-daily-report)# no mail-to-5
Router(config-daily-report)# smtp-auth activate
Router(config-daily-report)# smtp-auth username 12345 password pass12345
Router(config-daily-report)# schedule hour 13 minutes 57
Router(config-daily-report)# no reset-counter
Router(config-daily-report)# item cpu-usage
Router(config-daily-report)# item mem-usage
Router(config-daily-report)# item session-usage
Router(config-daily-report)# item port-usage
Router(config-daily-report)# item idp-report
Router(config-daily-report)# item av-report
Router(config-daily-report)# item traffic-report
Router(config-daily-report)# daily-report activate
