Chapter 12 Wireless Frame Capture
NXC CLI Reference Guide
110
The following table describes the commands available for wireless frame capture. You must
use the
configure terminal command to enter the configuration mode before you can use
these commands.
12.2.1 Wireless Frame Capture Examples
This example configures the wireless frame capture parameters for an AP located at IP address
192.168.1.2.
This example shows frame capture status and configuration.
Table 49 Command Summary: Wireless Frame Capture
COMMAND DESCRIPTION
frame-capture configure Enters sub-command mode for wireless frame capture.
src-ip {add|del} {ipv4_address |
local}
Sets or removes the IPv4 address of an AP controlled by
the NXC that you want to monitor. You can use this
command multiple times to add additional IPs to the
monitor list.
file-prefix file_name Sets the file name prefix for each captured file. Enter up
to 31 alphanumeric characters. Spaces and underscores
are not allowed.
files-size mon_dir_size Sets the total combined size (in kbytes) of all files to be
captured.
exit Exits configuration mode for wireless frame capture.
[no] frame-capture activate Starts wireless frame capture. Use the no parameter to
turn it off.
show frame-capture status Displays whether frame capture is running or not.
show frame-capture config Displays the frame capture configuration.
Router(config)# frame-capture configure
Router(frame-capture)# src-ip add 192.168.1.2
Router(frame-capture)# file-prefix monitor
Router(frame-capture)# files-size 1000
Router(frame-capture)# exit
Router(config)#
Router(config)# show frame-capture status
capture status: off
Router(config)# show frame-capture config
capture source: 192.168.1.2
file prefix: monitor
file size: 1000
