Chapter 1 Command Line Interface
NXC CLI Reference Guide
28
password Used in user and ip
1-63 alphanumeric or `~!@#$%^&*()_-+={}|\;:'<,>./
Used in e-mail log profile SMTP authentication
1-63 alphanumeric or `~!@#$%^&*()_-+={}|\;:'<>./
Used in device HA synchronization
1-63 alphanumeric or ~#%^*_-={}:,.
Used in registration
6-20 alphanumeric or .@_-
phone number 1-20 numbers or ,+
preshared key 16-64 “0x” or “0X” + 16-64 hexadecimal values
alphanumeric or ;|`~!@#$%^&*()_+\{}':,./<>=-
profile name 1-31 alphanumeric or _-
first character: letters or _-
proto name 1-16 lower-case letters, numbers, or -
protocol name 1-31 alphanumeric or _-
first character: letters or _-
quoted string less
than 255 chars
1-255 alphanumeric, spaces, or ;/?:@&=+$\.-_!~*'()%,
quoted string less
than 63 chars
1-63 alphanumeric, spaces, or ;/?:@&=+$\.-_!~*'()%
quoted string 0+ alphanumeric, spaces, or punctuation marks
enclosed in double quotation marks (“)
must put a backslash (\) before double quotation
marks that are part of input value itself
realm 1-253 alphanumeric or -_
first character: alphanumeric or -_
used in domain authentication
service name 0-63 alphanumeric or -_@$./
spi 2-8 hexadecimal
string less than 15
chars
1-15 alphanumeric or -_
string: less than 63
chars
1-63 alphanumeric or `~!@#$%^&*()_-+={}|\;:'<,>./
string 1+ alphanumeric or -_@
subject 1-61 alphanumeric, spaces, or '()+,./:=?;!*#@$_%-
system type 0-2 hexadecimal
timezone [-+]hh -- -12 through +12 (with or without “+”)
url 1-511 alphanumeric or '()+,/:.=?;!*#@$_%-
url “http://”+
“https://”+
alphanumeric or ;/?:@&=+$\.-_!~*'()%,
starts with “http://” or “https://”
may contain one pound sign (#)
user name 1-31 alphanumeric or _-
first character: letters or _-
Table 4 Input-Value Formats for Strings in CLI Commands (continued)
TAG # VALUES LEGAL VALUES
