Chapter 32 System Remote Management
NXC CLI Reference Guide
191
32.4.4 SSH Command Examples
This command sets a service control rule that allowed the computers with the IP addresses
matching the specified address object to access the specified zone using SSH service.
This command sets a certificate (Default) to be used to identify the NXC.
32.5 Telnet
You can configure your NXC for remote Telnet access.
[no] ip ssh server port <1..65535> Sets the SSH service port number. The no
command resets the SSH service port number to
the factory default (22).
ip ssh server rule {rule_number|append|insert
rule_number} access-group {ALL|address_object}
zone {ALL|zone_object} action {accept|deny}
Sets a service control rule for SSH service.
address_object: The name of the IP address
(group) object. You may use 1-31 alphanumeric
characters, underscores(
_), or dashes (-), but the
first character cannot be a number. This value is
case-sensitive.
zone_object: The name of the zone. Use up to
31 characters (a-zA-Z0-9_-). The name cannot
start with a number. This value is case-sensitive.
You can also use pre-defined zone names like
LAN and WLAN.
ip ssh server rule move rule_number to
rule_number
Changes the index number of a SSH service
control rule.
[no] ip ssh server v1 Enables remote management using SSH v1. The
no command stops the NXC from using SSH v1.
no ip ssh server rule rule_number Deletes a service control rule for SSH service.
show ip ssh server status Displays SSH settings.
Table 103 Command Summary: SSH (continued)
COMMAND DESCRIPTION
Router# configure terminal
Router(config)# ip ssh server rule 2 access-group Marketing zone LAN action
accept
Router# configure terminal
Router(config)# ip ssh server cert Default
