Zyxel NXC2500 [40/275] Here are examples of the commands that display the system uptime and model firmware and build information
![Zyxel NXC2500 [40/275] Here are examples of the commands that display the system uptime and model firmware and build information](/views2/1169008/page40/bg28.png)
Chapter 4 Status
NXC CLI Reference Guide
40
Here are examples of the commands that display the system uptime and model, firmware, and
build information.
This example shows the current LED states on the NXC. The SYS LED lights on and green.
Router> show system uptime
system uptime: 04:18:00
Router> show version
ZyXEL Communications Corp.
model : NXC5200
firmware version: 2.20(AQQ.0)b3
BM version : 1.08
build date : 2009-11-21 01:18:06
Router> show led status
sys: green
Router>
