![Zyxel NXC2500 [35/275] Object reference](/views2/1169008/page35/bg23.png)
NXC CLI Reference Guide
35
CHAPTER 3
Object Reference
This chapter describes how to use object reference commands.
3.1 Object Reference Commands
The object reference commands are used to see which configuration settings reference a
specific object. You can use this table when you want to delete an object because you have to
remove references to the object first.
Table 7 show reference Commands
COMMAND DESCRIPTION
show reference object username
[username]
Displays which configuration settings reference the
specified user object.
show reference object address
[profile]
Displays which configuration settings reference the
specified address object.
show reference object service
[profile]
Displays which configuration settings reference the
specified service object.
show reference object schedule
[profile]
Displays which configuration settings reference the
specified schedule object.
show reference object aaa
authentication [default |
auth_method]
Displays which configuration settings reference the
specified AAA authentication object.
show reference object ca
category {local|remote}
[cert_name]
Displays which configuration settings reference the
specified authentication method object.
show reference object zone
[profile]
Displays which configuration settings reference the
specified zone object.
show reference object-group
username [username]
Displays which configuration settings reference the
specified user group object.
show reference object-group
address [profile]
Displays which configuration settings reference the
specified address group object.
show reference object-group
service [profile]
Displays which configuration settings reference the
specified service group object.
show reference object-group
interface [profile]
Displays which configuration settings reference the
specified trunk object.
show reference object-group aaa
ad [group_name]
Displays which configuration settings reference the
specified AAA AD group object.
show reference object-group aaa
ldap [group_name]
Displays which configuration settings reference the
specified AAA LDAP group object.
