Chapter 29 ENC
NXC CLI Reference Guide
174
enc-agent periodic-inform
interval <10..86400>
Sets how often (in seconds) the NXC sends Inform messages to
initiate connections to the ENC or ACS server.
enc-agent authentication
enable
Sets the NXC to authenticate the ENC or ACS server’s
certificate when you are using HTTPs. In order to do this you
need to import the ENC or ACS server’s public key (certificate)
into the NXC’s trusted certificates.
enc-agent server
certificate
certificate_name
Specifies the certificate of the ENC or ACS server.
certificate_name: The name of the certificate. You can use
up to 31 alphanumeric and ;‘~!@#$%^&()_+[]{}’,.=-
characters.
enc-agent acs username
username
Specifies the user name used to authenticate the ACS server
when the server makes a connection request.
username: You may use up to 254 alphanumeric characters,
underscores(
_), or dashes (-). This value is case-sensitive.
enc-agent acs password
password
Specifies the password used to authenticate the ACS server
when the server makes a connection request.
password: You may use up to 254 alphanumeric characters,
underscores(
_), or dashes (-). This value is case-sensitive.
enc-agent username
username
Specifies the NXC’s user name for authentication with the ENC
server.
username: You may use up to 254 alphanumeric characters,
underscores(
_), or dashes (-). This value is case-sensitive.
enc-agent password
password
Specifies the NXC’s password for authentication with the ENC
server.
password: You may use up to 254 alphanumeric characters,
underscores(
_), or dashes (-). This value is case-sensitive.
enc-agent server-type {enc
|tr069}
Specifies the type of the management server.
enc-agent my-ip auto Sets the NXC to allow management sessions to connect to any
of the NXC’s IP addresses.
enc-agent my-ip custom
ipv4_address
Specify the NXC’s IP address that allows management
sessions.
enc-agent trigger-inform
<0..8640>
The NXC can connect to the server automatically by sending an
Inform message.
Specifies after how many seconds the NXC sends an Inform
message to initiate a TR069 connection to the ENC or ACS
server.
no enc-agent manager Disables the ENC agent feature on the NXC.
no enc-agent
authentication
Sets the NXC to not authenticate the ENC or ACS server’s
certificate when you are using HTTPs.
no enc-agent server
certificate
Removes the certificate of the ENC or ACS server.
no enc-agent acs username Removes the user name used to authenticate the ENC or ACS
server when the server makes a connection request.
no enc-agent acs password Removes the password used to authenticate the ENC or ACS
server when the server makes a connection request.
no enc-agent username Removes the NXC’s user name for authentication with the ENC
or ACS server.
no enc-agent password Removes the NXC’s password for authentication with the ENC
or ACS server.
Table 92 Command Summary: ENC-Agent (continued)
COMMAND DESCRIPTION
