NXC CLI Reference Guide
105
CHAPTER 11
Rogue AP
This chapter shows you how to set up Rogue Access Point (AP) detection and containment.
11.1 Rogue AP Detection Overview
Rogue APs are wireless access points operating in a network’s coverage area that are not under
the control of the network’s administrators, and can potentially open holes in the network
security. Attackers can take advantage of a rogue AP’s weaker (or non-existent) security to
gain illicit access to the network, or set up their own rogue APs in order to capture information
from wireless clients.
Conversely, a friendly AP is one that the NXC network administrator regards as non-
threatening. This does not necessarily mean the friendly AP must belong to the network
managed by the NXC; rather, it is any unmanaged AP within range of the NXC’s own wireless
network that is allowed to operate without being contained. This can include APs from
neighboring companies, for example, or even APs maintained by your company’s employees
that operate outside of the established network.
11.2 Rogue AP Detection Commands
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
The following table describes the commands available for rogue AP detection. You must use
the
configure terminal command to enter the configuration mode before you can use
these commands.
Table 44 Input Values for Rogue AP Detection Commands
LABEL DESCRIPTION
ap_mac Specifies the MAC address (in XX:XX:XX:XX:XX:XX format) of the AP
to be added to either the rogue AP or friendly AP list. The no command
removes the entry.
description2 Sets the description of the AP. You may use 1-60 alphanumeric
characters, underscores (
_), or dashes (-). This value is case-sensitive.
Table 45 Command Summary: Rogue AP Detection
COMMAND DESCRIPTION
rogue-ap detection Enters sub-command mode for rogue AP detection.
[no] activate Activates rogue AP detection. Use the no parameter to
deactivate rogue AP detection.
