![Zyxel NXC2500 [87/275] Wireless lan profiles](/views2/1169008/page87/bg57.png)
NXC CLI Reference Guide
87
CHAPTER 10
Wireless LAN Profiles
This chapter shows you how to configure wireless LAN profiles on your NXC.
10.1 Wireless LAN Profiles Overview
The managed Access Points designed to work explicitly with your NXC do not have on-board
configuration files, you must create “profiles” to manage them. Profiles are preset
configurations that are uploaded to the APs and which manage them. They include: Radio and
Monitor profiles, SSID profiles, Security profiles, MAC Filter profiles, and Layer-2 isolation
profiles. Altogether, these profiles give you absolute control over your wireless network.
10.2 AP Radio & Monitor Profile Commands
The radio profile commands allow you to set up configurations for the radios onboard your
various APs. The monitor profile commands allow you to set up monitor mode configurations
that allow your APs to scan for other APs in the vicinity.
The following table identifies the values required for many of these commands. Other input
values are discussed with the corresponding commands.
Table 32 Input Values for General Radio and Monitor Profile Commands
LABEL DESCRIPTION
radio_profile_name The radio profile name. You may use 1-31 alphanumeric characters,
underscores (
_), or dashes (-), but the first character cannot be a
number. This value is case-sensitive.
monitor_profile_name The monitor profile name. You may use 1-31 alphanumeric characters,
underscores (
_), or dashes (-), but the first character cannot be a
number. This value is case-sensitive.
interval Enters the dynamic channel selection interval time. The range is 10 ~
1440 minutes.
wlan_role Sets the wireless LAN radio operating mode. At the time of writing, you
can use ap for Access Point.
wireless_channel_2g Sets the 2 GHz channel used by this radio profile. The channel range is
1 ~ 14.
Note: Your choice of channel may be restricted by
regional regulations.
