NXC CLI Reference Guide
181
CHAPTER 31
System
This chapter provides information on the commands that correspond to what you can
configure in the system screens.
31.1 System Overview
Use these commands to configure general NXC information, the system time and the console
port connection speed for a terminal emulation program. They also allow you to configure
DNS settings and determine which services/protocols can access which NXC zones (if any)
from which computers.
31.2 Customizing the WWW Login Page
Use these commands to customize the Web Configurator login screen. You can also customize
the page that displays after an access user logs into the Web Configurator to access network
services like the Internet.
The following figures identify the parts you can customize in the login and access pages.
Figure 14 Login Page Customization
Logo
Title
Message Color
Background
(color of all text)
Note Message
(last line of text)
