Zyxel NXC2500 [197/275] Tr 069 commands
![Zyxel NXC2500 [197/275] Tr 069 commands](/views2/1169008/page197/bgc5.png)
Chapter 32 System Remote Management
NXC CLI Reference Guide
197
32.9.1 TR-069 Commands
The following table describes the commands available for TR-069. You must use the
configure terminal command to enter the configuration mode before you can use these
commands.
Table 108 Command Summary: TR-069
COMMAND DESCRIPTION
[no] tr069-agent acs password password Enters up to 255 characters to set the password
used to authenticate the NXC when making a
connection to the management server. The no
command removes the password.
[no] tr069-agent acs username username Enters up to 255 characters to set the user name
used to authenticate the NXC when making a
connection to the management server. The
no
command removes the user name.
[no] tr069-agent activate Allows the NXC to be managed by a
management server. The no command disables
TR-069 (CWMP).
[no] tr069-agent authentication enable Sets the NXC to authenticate the management
server’s certificate when you are using
HTTPs.The
no command disables
authentication.
[no] tr069-agent connection-request-url
{https_url> | http_url}
Sets the IP address or domain name of the NXC.
The management server uses this path to verify
the NXC.
The
no command removes the NXC address
setting.
tr069-agent keepalive interval <10..90> Sets the time interval
[no] tr069-agent manager {https_url> | http_url} Sets the IP address or domain name of the
management server (or Auto Configuration
Server (ACS)). The
no command removes the
server setting.
[no] tr069-agent my-ip {auto | custom
ipv4_address}
Sets the
auto: to have the NXC allow management
sessions to connect to any of the NXC’s IP
addresses.
custom: to specify the NXC’s IP address that
allows management sessions.
[no] tr069-agent password password Enters up to 255 characters to set the password
used to authenticate the management server
when connecting to the NXC. The
no command
removes the password.
tr069-agent pause keepalive <0..8640>
[no] tr069-agent periodic-inform activate Sets the NXC to periodically send information to
the management server (recommended if CWMP
is enabled). The
no command disables the
periodic inform.
tr069-agent periodic-inform interval
<10..86400>
Sets the duration in seconds for which the NXC
must attempt to connect with the management
server to send information and check for
configuration updates.
tr069-agent server-type {tr069 | vantage} Sets the type of the management server.
tr069-agent trigger-inform <0..8640>
