Chapter 10 Wireless LAN Profiles
NXC CLI Reference Guide
89
band {2.4G |5G} band-mode
{bg | bgn | a | ac | an}
Sets the radio band (2.4 GHz or 5 GHz) and band mode
for this profile. Band mode details:
For 2.4 GHz, bg lets IEEE 802.11b and IEEE 802.11g
clients associate with the AP.
For 2.4 GHz, bgn lets IEEE 802.11b, IEEE 802.11g, and
IEEE 802.11n clients associate with the AP.
For 5 GHz, a lets only IEEE 802.11a clients associate
with the AP.
For 5 GHz, ac lets IEEE 802.11a, IEEE 802.11n, and
IEEE 802.11ac clients associate with the AP.
For 5 GHz, an lets IEEE 802.11a and IEEE 802.11n
clients associate with the AP.
beacon-interval <40..1000> Sets the beacon interval for this profile.
When a wirelessly networked device sends a beacon, it
includes with it a beacon interval. This specifies the time
period before the device sends the beacon again. The
interval tells receiving devices on the network how long
they can wait in low-power mode before waking up to
handle the beacon. This value can be set from 40ms to
1000ms. A high value helps save current consumption of
the access point.
The default is 100.
country-code country_code Sets the country where the NXC is located/installed.
The available channels vary depending on the country
you selected. Be sure to select the correct/same country
for both radios on an AP and all connected APs, in order
to prevent roaming failure and interference to other
systems.
country_code: 2-letter country-codes, such as TW, DE,
or FR.
[no] dcs activate Starts dynamic channel selection. Use the no parameter
to turn it off.
dcs 2g-selected-channel 2.4g_channels Sets the channels that are available in the 2.4 GHz band
when you manually configure the channels an AP can
use.
dcs dcs-2g-method {auto|manual} Sets the AP to automatically search for available
channels or manually configures the channels the AP
uses in the 2.4 GHz band.
dcs dcs-5g-method {auto} Sets the AP to automatically search for available
channels.
dcs client-aware {enable|disable} When enabled, this ensures that an AP will not change
channels as long as a client is connected to it. If disabled,
the AP may change channels regardless of whether it has
clients connected to it or not.
dcs channel-deployment {3-channel|4-
channel}
Sets either a 3-channel deployment or a 4-channel
deployment.
In a 3-channel deployment, the AP running the scan
alternates between the following channels: 1, 6, and 11.
In a 4-channel deployment, the AP running the scan
alternates between the following channels: 1, 4, 7, and 11
(FCC) or 1, 5, 9, and 13 (ETSI).
Sets the option that is applicable to your region. (Channel
deployment may be regulated differently between
countries and locales.)
Table 33 Command Summary: Radio Profile (continued)
COMMAND DESCRIPTION
