Chapter 11 Rogue AP
NXC CLI Reference Guide
107
This example shows the friendly AP detection list.
This example shows the combined rogue and friendly AP detection list.
This example shows both the status of rogue AP detection and the summary of detected APs.
11.3 Rogue AP Containment Overview
These commands enable rogue AP containment. You can use them to isolate a device that is
flagged as a rogue AP. They are global in that they apply to all managed APs on the network
(all APs utilize the same containment list, but only APs set to monitor mode can actively
engage in containment of rogue APs). This means if we add a MAC address of a device to the
containment list, then every AP on the network will respect it.
Router(config)# show rogue-ap detection list friendly
no. mac description
===========================================================================
1 11:11:11:11:11:11 third floor
2 00:13:49:11:22:33
3 00:13:49:00:00:05
4 00:13:49:00:00:01
5 00:0D:0B:CB:39:33 dept1
Router(config)# show rogue-ap detection list all
no. role mac description
===========================================================================
1 friendly-ap 11:11:11:11:11:11 third floor
2 friendly-ap 00:13:49:11:22:33
3 friendly-ap 00:13:49:00:00:05
4 friendly-ap 00:13:49:00:00:01
5 friendly-ap 00:0D:0B:CB:39:33 dept1
6 rogue-ap 00:13:49:18:15:5A
Router(config)# show rogue-ap detection status
rogue-ap detection status: on
Router(config)# show rogue-ap detection info
rogue ap: 1
friendly ap: 4
adhoc: 4
unclassified ap: 0
total devices: 0
