Chapter 19 Captive Portal
NXC CLI Reference Guide
128
19.1.1.1 web-auth login setting Sub-commands
The following table describes the sub-commands for the web-auth login setting
command.
web-auth login setting Sets the login web page through which the user authenticate their
connections before connecting to the rest of the network or Internet.
See Table 60 on page 128 for the sub-commands.
web-auth policy <1..1024> Creates the specified condition for forcing user authentication, if
necessary, and enters sub-command mode. The NXC checks the
conditions in sequence, starting at 1. See Table 61 on page 129 for
the sub-commands.
web-auth policy append Creates a new condition for forcing user authentication at the end of
the current list and enters sub-command mode. See Table 61 on
page 129 for the sub-commands.
web-auth policy delete <1..1024> Deletes the specified condition.
web-auth policy flush Deletes all the conditions for forcing user authentication.
web-auth policy insert <1..1024> Creates a new condition for forcing user authentication at the
specified location, renumbers the other conditions accordingly, and
enters sub-command mode. See Table 61 on page 129 for the sub-
commands.
web-auth policy move <1..1024> to
<1..1024>
Moves the specified condition to the specified location and
renumbers the other conditions accordingly.
show web-auth activation Displays whether forcing user authentication is enabled or not.
show web-auth authentication Displays the name of authentication method used for the captive
portal page.
show web-auth default-rule Displays the default captive portal authentication settings the NXC
uses on traffic not matching any exceptional service or other
authentication policy.
show web-auth exceptional-service Displays services that users can access without user authentication.
show web-auth policy {<1..1024> |
all}
Displays details about the policies for forcing user authentication.
show web-auth status Displays the web portal page settings.
Table 59 Web Authentication Policy Commands (continued)
COMMAND DESCRIPTION
Table 60 web-auth login setting Sub-commands
COMMAND DESCRIPTION
exit Leaves the sub-command mode.
type {external |
internal}
Sets which login page appears whenever the web portal intercepts network
traffic, preventing unauthorized users from gaining access to the network.
internal: Use the default login page built into the NXC.
external: Use a custom login page from an external web portal. You can
configure the look and feel of the web portal page.
[no] error-url <url> Sets the error page’s URL; for example: http://192.168.1.1/error.cgi.
192.168.1.1 is the web server on which the web portal files are installed.
[no] login-url <url> Sets the login page’s URL; for example: http://192.168.1.1/login.cgi.
192.168.1.1 is the web server on which the web portal files are installed.
[no] logout-url <url> Sets the logout page’s URL; for example: http://192.168.1.1/logout.cgi.
192.168.1.1 is the web server on which the web portal files are installed.
