Chapter 26 AAA Server
NXC CLI Reference Guide
162
26.2.1 aaa group server ad Commands
The following table lists the aaa group server ad commands you use to configure a
group of AD servers.
Table 86 aaa group server ad Commands
COMMAND DESCRIPTION
clear aaa group server ad [group-
name]
Deletes all AD server groups or the specified AD
server group.
Note: You can NOT delete a server group
that is currently in use.
show aaa group server ad group-
name
Displays the specified AD server group settings.
[no] aaa group server ad group-
name
Sets a descriptive name for an AD server group. Use
this command to enter the sub-command mode.
The
no command deletes the specified server group.
aaa group server ad rename group-
name group-name
Changes the descriptive name for an AD server group.
aaa group server ad group-name Enter the sub-command mode to configure an AD
server group.
[no] server alternative-cn-
identifier uid
Sets the second type of identifier that the users can
use to log in if any. For example “name” or “e-mail
address”. The
no command clears this setting.
[no] server basedn basedn Sets a base distinguished name (DN) to point to the
AD directory on the AD server group. The
no
command clears this setting.
[no] server binddn binddn Sets the user name the NXC uses to log into the AD
server group. The no command clears this setting.
[no] server cn-identifier uid Sets the unique common name (cn) to identify a
record. The
no command clears this setting.
[no] server description
description
Sets the descriptive information for the AD server
group. You can use up to 60 printable ASCII
characters. The no command clears the setting.
[no] server group-attribute
group-attribute
Sets the name of the attribute that the NXC is to check
to determine to which group a user belongs. The value
for this attribute is called a group identifier; it
determines to which group a user belongs. You can
add ext-group-user user objects to identify groups
based on these group identifier values.
For example you could have an attribute named
“memberOf” with values like “sales”, “RD”, and
“management”. Then you could also create an ext-
group-user user object for each group. One with
“sales” as the group identifier, another for “RD” and a
third for “management”. The
no command clears the
setting.
[no] server host ad_server Enter the IP address (in dotted decimal notation) or the
domain name of an AD server to add to this group. The
no command clears this setting.
[no] server password password Sets the bind password (up to 15 alphanumerical
characters). The
no command clears this setting.
