Chapter 27 Authentication Objects
NXC CLI Reference Guide
169
27.3 test aaa Command
The following table lists the test aaa command you use to teat a user account on an
authentication server.
27.3.1 Test a User Account Command Example
The following example shows how to test whether a user account named userABC exists on
the AD authentication server which uses the following settings:
• IP address: 172.16.50.1
• Port: 389
• Base-dn: DC=ZyXEL,DC=com
• Bind-dn: zyxel\engineerABC
• Password: abcdefg
• Login-name-attribute: sAMAccountName
The result shows the account exists on the AD server. Otherwise, the NXC returns an error.
Table 90 test aaa Command
COMMAND DESCRIPTION
test aaa {server|secure-
server} {ad|ldap} host
{hostname|ipv4-address}
[host {hostname|ipv4-
address}] port <1..65535>
base-dn base-dn-string
[bind-dn bind-dn-string
password password] login-
name-attribute attribute
[alternative-login-name-
attribute attribute]
account account-name
Tests whether a user account exists on the specified
authentication server.
Router> test aaa server ad host 172.16.50.1 port 389 base-dn DC=ZyXEL,DC=com
bind-dn zyxel\engineerABC password abcdefg login-name-attribute
sAMAccountName account userABC
dn:: Q049MTIzNzco546L5aOr56uRKSxPVT1XaXRoTWFpbCxEQz1aeVhFTCxEQz1jb20=
objectClass: top
objectClass: person
objectClass: organizationalPerson
objectClass: user
cn:: MTIzNzco546L5aOr56uRKQ==
sn: User
l: 2341100
--------------------------SNIP!--------------------------------------------
