Chapter 31 System
NXC CLI Reference Guide
184
31.4.1 Date/Time Commands
The following table describes the commands available for date and time setup. You must use
the
configure terminal command to enter the configuration mode before you can use
these commands.
Table 97 Command Summary: Date/Time
COMMAND DESCRIPTION
clock date <yyyy-mm-dd> time <hh:mm:ss> Sets the new date in year, month and day format
manually and the new time in hour, minute and
second format.
[no] clock daylight-saving Enables daylight saving. The no command
disables daylight saving.
[no] clock saving-interval begin
{apr|aug|dec|feb|jan|jul|jun|mar|may|nov|oct|se
p} {1|2|3|4|last} {fri|mon|sat|sun|thu|tue|wed}
hh:mm end
{apr|aug|dec|feb|jan|jul|jun|mar|may|nov|oct|se
p} {1|2|3|4|last} {fri|mon|sat|sun|thu|tue|wed}
hh:mm offset
Configures the day and time when Daylight
Saving Time starts and ends. The
no command
removes the day and time when Daylight Saving
Time starts and ends.
offset: a number from 1 to 5.5 (by 0.5 increments)
clock time hh:mm:ss Sets the new time in hour, minute and second
format.
[no] clock time-zone {-|+hh} Sets your time zone. The
no command removes
time zone settings.
[no] ntp Saves your date and time and time zone settings
and updates the data and time every 24 hours.
The
no command stops updating the data and
time every 24 hours.
[no] ntp server {fqdn|w.x.y.z} Sets the IP address or URL of your NTP time
server. The no command removes time server
information.
ntp sync Gets the time and date from a NTP time server.
show clock date Displays the current date of your NXC.
show clock status Displays your time zone and daylight saving
settings.
show clock time Displays the current time of your NXC.
show ntp server Displays time server settings.
