NXC CLI Reference Guide
31
CHAPTER 2
User and Privilege Modes
This chapter describes how to use these two modes.
2.1 User And Privilege Modes
This is the mode you are in when you first log into the CLI. (Do not confuse ‘user mode’ with
types of user accounts the NXC uses. See Chapter 22 on page 143 for more information about
the user types. ‘User’ type accounts can only run ‘exit’ in this mode. However, they may need
to log into the device in order to be authenticated for ‘user-aware’ policies, for example a
firewall rule that a particular user is exempt from.)
Type ‘enable’ to go to ‘privilege mode’. No password is required. All commands can be run
from here except those marked with an asterisk. Many of these commands are for trouble-
shooting purposes, for example the htm (hardware test module) and debug commands.
Customer support may ask you to run some of these commands and send the results if you
need assistance troubleshooting your device.
For admin logins, all commands are visible in ‘user mode’ but not all can be run there. The
following table displays which commands can be run in ‘user mode’. All commands can be
run in ‘privilege mode’.
The htm and psm commands are for ZyXEL’s internal manufacturing process.
Table 5 User (U) and Privilege (P) Mode Commands
COMMAND MODE DESCRIPTION
apply P Applies a configuration file.
atse U/P Displays the seed code
clear U/P Clears system or debug logs or DHCP binding.
configure U/P Use ‘configure terminal’ to enter configuration mode.
copy P Copies configuration files.
debug (*) U/P For support personnel only! The device needs to have the debug flag enabled.
delete P Deletes configuration files.
details P Performs diagnostic commands.
diag P Provided for support personnel to collect internal system information. It is not
recommended that you use these.
