Chapter 15 Dynamic Guest
NXC CLI Reference Guide
117
15.2.1 Dynamic Guest Examples
This example creates a guest-manager user account and a dynamic-guest user group, then sets
the NXC to generate two dynamic-guest accounts automatically. This also shows the dynamic
guest users information.
Router(config)# username GuestMaster password 4321 user-type guest-manager
Router(config)# groupname dynamic-guest
Router(group-user)# dynamic-guest group
Router(group-user)# exit
Router(config)# dynamic-guest generate 2
Router(config-dynamic-guest)# company example
Router(config-dynamic-guest)# group dynamic-guest
Router(config-dynamic-guest)# expire-time 2013-06-16 14:00
Router(config-dynamic-guest)# exit
[dynamic guest] username:N84AVAJN, password:QAA3KJ63
[dynamic guest] username:S6F8PZ3N, password:66DA3BCX
Router(config)# show dynamic-guest
Client: N84AVAJN
guest name:
phone:
e-mail:
address:
company: example
expire time: 2013-06-16 14:00
group: dynamic-guest
others:
expire: no
Client: S6F8PZ3N
guest name:
phone:
e-mail:
address:
company: example
expire time: 2013-06-16 14:00
group: dynamic-guest
others:
expire: no
Router(config)#
