Package Contents
The following items should be found in your box:
One JetStream Gigabit L2 Managed Switch
One power cord
Two mounting brackets and other fittings
Installation Guide
Resource CD for T2600G-28TS/ T2600G-52TS/ T2600G-28MPS, including:
• This User Guide
• CLI Reference Guide
• SNMP Mibs
• 802.1X Client Software and its User Guide
• USB Console Driver
• Other Helpful Information
Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact your distributor.
