4.3.5 System Reboot
On this page you can reboot the switch and return to the login page. Please save the current
configuration before rebooting to avoid losing the configuration unsaved.
Choose the menu System→System Tools→System Reboot to load the following page.
Figure 4-14 System Reboot
Note:
To avoid damage, please don't turn off the device while rebooting.
4.3.6 Reboot Schedule
On this page you can schedule a reboot plan for the switch. Users can configure the reboot
schedule in two modes. The first one is to reboot the switch in a specific time interval. The
second one is to reboot the switch at a specific time and date.
Users can choose whether to save the configurations before the reboot. If Save Before
Reboot is not checked, the reboot schedule will be deleted after the next reboot.
Choose the menu System→System Tools→Reboot Schedule to load the following page.
Figure 4-15 Reboot Schedule Setting
The following entries are displayed on this screen:
Reboot Schedule Setting
27
