Tp-Link T2600G-28MPS (TL-SG3424P) [33/379] Serial port setting

Note:

1. When the DST is disabled, the predefined mode, recurring mode and date mode cannot be

configured.

2. When the DST is enabled, the default daylight saving time is of European in predefined

mode.

4.1.5 Serial Port Setting

On this page you can configure the Baud Rate of the console connection.

Choose the menu System→System Info→Serial Port Setting to load the following page.

Figure 4-7 User Table

The following entries are displayed on this screen:



Serial Port Settings

Baud Rate: Configure the baud rate of the console connection

. It is 38400

bps by default.

Data Bits:

Displays the default data bits.

Parity Bits:

Displays the parity bits.

Stop Bits:

Displays the stop bits.

4.2 User Management

User Management functions to configure the user name and password for users to log on to

the Web management page with a certain access level so as to protect the settings of the

switch from being randomly changed.

The User Management function can be implemented on User Table and User Config pages.

4.2.1 User Table

On this page you can view the information about the current users of the switch.

Choose the menu System→User Management→User Table to load the following page.
