Tp-Link T2600G-28MPS (TL-SG3424P) [163/379] Vlan config

Fast Leave:

Select Enable/Disable Fast Leave feature for the desired port. If

Fast Leave is enabled for a port, the switch will immediately

remove this port from the multicast group upon receiving IGMP

leave messages.

LAG:

Displays the LAG number which the port belongs to.

Note:

1. Fast Leave on the port is effective only when the host supports IGMPv2 or IGMPv3.

2. When both Fast Leave feature and Unknown Multicast Discard feature are enabled, the

leaving of a user connected to a port owning multi-user will result in the other users

intermitting the multicast business.

9.1.3 VLAN Config

Multicast groups established by IGMP Snooping are based on VLANs. On this page you can

configure different IGMP parameters for different VLANs.

Choose the menu Multicast→IGMP Snooping→VLAN Config to load the following page.

Figure 9-7 VLAN Config

The following entries are displayed on this screen:



VLAN Config

VLAN ID: Enter the VLAN ID to enable IGMP Snooping for the desir

VLAN.

151
