Tp-Link T2600G-28MPS (TL-SG3424P) [243/379] Voice vlan
![Tp-Link T2600G-28MPS (TL-SG3424P) [243/379] Voice vlan](/views2/1210070/page243/bgf3.png)
The following entries are displayed on this screen:
Storm Control Config
UNIT:1/LAGS:
Click 1 to configure the physical ports. Click LAGS
to configure
the link aggregation groups.
Select:
Select the desire
d port for Storm Control configuration. It is
multi-optional.
Port:
Displays the port number of the switch.
PPS:
Enable or disable the PPS mode.
Broadcast Rate
Mode:
Select the broadcast rate mode, pps mode is invalid if the PPS
is disabled.
kbps: Specify the threshold in kbits per second.
ratio
: Specify the threshold as a percentage of the
bandwidth.
pps: Specify the threshold in packets per second.
Broadcast:
Enable/Disable broadcast control feature for the port.
Mulitcast Rate
Mode:
Select the mult
icast rate mode, pps mode is invalid if PPS is
disabled.
Multicast:
Enable/Disable multicast control feature for the port.
UL-Frame Rate
Mode:
Select the UL-
Frame rate mode, pps mode is invalid if PPS is
disabled.
UL-Frame:
Enable/Disable UL-Frame control feature for the port.
LAG:
Displays the LAG number which the port belongs to.
Note:
1. If you enable storm control feature for the ingress rate limit-enabled port, ingress rate limit
feature will be disabled for this port.
2. If the PPS function is enabled, the storm control type can ONLY be pps. If the PPS function
is disabled, the storm control type can be set as kbps or ratio.
11.3 Voice VLAN
Voice VLANs are configured specially for voice data stream. By configuring Voice VLANs and
adding the ports with voice devices attached to voice VLANs, you can perform QoS-related
configuration for voice data, ensuring the transmission priority of voice data stream and voice
quality.
OUI Address (Organizationally unique identifier address)
231
