Configuration Procedure:

Step

Operation

Description

Bind the IP address, MAC

address, VLAN ID and the

connected Port number of

the Host together.

Required. On the IP-MAC Binding

page, bind the IP

address,

MAC address, VLAN ID and the connected

Port number of the Host together via Manual Binding,

ARP Scanning or DHCP Snooping.

Enable the protection for

the bound entry.

Required. On the Network Security→IP-MAC

Binding→Binding Table

page, specify a protect type

for the corresponding bound entry.

Specify the trusted port. Required. On the Network Security→ARP

Inspection→ARP Detect

page, specify the trusted port.

The specific ports, such as up-linked port, routing port

and LAG port, should be set as Trusted Port.

Enable ARP Detect feature. Required. On the Network Security→ARP

Inspection→ARP Detect page, enable the ARP Detect

feature.

14.5.2 ARP Defend

With the ARP Defend enabled, the switch can terminate receiving the ARP packets for 300

seconds when the transmission speed of the legal ARP packet on the port exceeds the defined

value so as to avoid ARP Attack flood.

Choose the menu Network Security→ARP Inspection→ARP Defend to load the following

page.

Figure 14-20 ARP Defend

The following entries are displayed on this screen:
