Router Port Time: Enter the glob
al router port aging time. If the router port does
not receive Query Message in the aging time, it will be aged.
Member Port Time:
Enter the global member port aging time. If the member port
does not receive Report Message in the aging time, it will be
aged.
Last Listener Query
Interval:
Enter the interval between the switch sends out MASQs.
Last Listener Query
Count:
Enter the number of MASQs that the switch sends before aging
out a multicast address when there is no MLD report response.
MLD Snooping Status
Description:
Displays MLD Snooping status.
Member:
Displays the member of the corresponding status.
Note:
1. Configurations of the Router Port Time and Member Port Time in 8.2.3 VLAN Config
override their global configurations here.
3. Before creating a Multicast VLAN, you should enable the MLD snooping function in this
VLAN in 8.2.3 VLAN Config.
Configuration Procedure of Multicast VLAN:
Step
Operation
Description
1
Create VLAN. Required. On the VLAN →802.1Q VLAN →VLAN Config
page, click the Create button to create a VLAN. Enter the
VLAN ID and the description for the VLAN. Meanwhile,
specify its member ports.
2
Enable MLD Snooping
globally.
Required. On the Multicast →MLD Snooping →Global
Config page, enable the MLD Snooping function globally.
3
Enable MLD Snooping in
the VLAN.
Required. On the Multicast →MLD Snooping →VLAN
Config page, specify the VLAN ID as the VLAN created in
step 1.
4
Enable the Multicast VLAN. Required. On the Multicast →MLD Snooping →Multicast
page, enable the Multicast VLAN function and specify the
Multicast VLAN ID as the VLAN specified in Step 1.
167
