Clear Binding: Click the ClearBinding

button to clear all profiles bound to the

port.



Configuration Procedure:

Step

Operation

Description

1 Create Profile

Required. Configure the Profile ID and mode on

Multicast→IGMP Snooping→Profile Config page.

2 Configure IP-Range Required. Click Edit

of the specified entry in the IGMP

Profile Info table on Multicast→IGMP Snooping→Profile

Config page to configure the mode or IP-

range of the

Profile.

3 Configure Profile Binding

for ports

Optional. Configure Profile Binding for ports on

Multicast→IGPM Snooping→Porfile Binding page.

9.1.8 Packet Statistics

On this page you can view the multicast data traffic on each port of the switch, which facilitates

you to monitor the IGMP messages in the network.

Choose the menu Multicast→IGMP Snooping→Packet Statistics to load the following page.

Figure 9-12 Packet Statistics

161
