Tp-Link T2600G-28MPS (TL-SG3424P) [268/379] Policy config

D-IP: Enter the destination

IPv6 address contained in the rule, you

can input all the 128 bits, but only upper 64 bits are verified.

Mask: Enter IP address mask. If it is set to 1, the upper 64 bit

s in the

destination address of the packet must strictly match the D-

IP you

configured. This field is 64-bit long.

S-Port: Configure L4

source port contained in the rule when TCP/UDP is

defined.

D-Port: Configure L4 destination port contained in the rule

when TCP/UDP is

defined.

Time-Range:

Select the time-range for the rule to take effect.

Note:

Before binding an IPv6 ACL to an interface or VLAN, you should configure the SDM template as

“enterpriseV6” and save your configurations. See SDM Template for more information about

SDM template configuration.

13.3 Policy Config

A Policy is used to control the data packets those match the corresponding ACL rules by

configuring ACLs and actions together for effect.

The Policy Config can be implemented on Policy Summary, Police Create and Action Create

pages.

13.3.1 Policy Summary

On this page, you can view the ACL and the corresponding operations in the policy.

Choose the menu ACL→Policy Config→Policy Summary to load the following page.

Figure 13-11 Policy Summary

The following entries are displayed on this screen:



Search Option

Select Policy: Select name of the desired policy for

view. If you want to delete

the desired policy, please click the Delete button.



Action Table

Select:

Select the desired entry to delete the corresponding policy.

256
