Chapter 2 Introduction

Thanks for choosing the T2600G-28TS/ T2600G-52TS/ T2600G-28MPS JetStream Gigabit L2

Managed Switch!

2.1 Overview of the Switch

Designed for workgroups and departments, T2600G-28TS/ T2600G-52TS/ T2600G-28MPS

from TP-Link provides wire-speed performance and full set of L2 and L2+ management

features. It provides a variety of service features and multiple powerful functions with high

security.

The EIA-standardized framework and smart configuration capacity can provide flexible

solutions for a variable scale of networks. Static routing allows devices in different

VLANs/subnets to communicate with each other in an IPv4/IPv6 network. OAM, L2PT and

sFlow can meet the requirement of large ISP customers. ACL, 802.1x and Dynamic ARP

Inspection provide robust security strategies. QoS and IGMP snooping/filtering optimize voice

and video application. Link aggregation (LACP) increases aggregated bandwidth, optimizing the

transport of business critical data. SNMP, RMON, WEB and CLI Log-in bring abundant

management policies. TP-Link JetStream L2 Managed Switch integrates multiple functions

with excellent performance, and is friendly to manage, which can fully meet the need of the

users demanding higher networking performance.

2.2 Appearance Description

2.2.1 Front Panel

The front panel of T2600G-28TS is shown as Figure 2-1.

T2600G-28

Figure 2-1 Front Panel of T2600G-28TS

The following parts are located on the front panel of T2600G-28TS:

 LEDs

Name

Status

Indication

PWR

The switch is powered on.

Off

The switch is powered off or power supply is

abnormal.

Flashing

Power supply is abnormal.

SYS

Flashing

The switch works properly.

On/Off

The switch works improperly.
