Tp-Link T2600G-28MPS (TL-SG3424P) [241/379] Bandwidth control

Step

Operation

Description

3 Select a schedule mode

Required. On QoS→DiffServ→Schedule Mode page,

select a schedule mode.

11.2 Bandwidth Control

Bandwidth function, allowing you to control the traffic rate and broadcast flow on each port to

ensure network in working order, can be implemented on Rate Limit and Storm Control pages.

11.2.1 Rate Limit

Rate limit functions to control the ingress/egress traffic rate on each port via configuring the

available bandwidth of each port. In this way, the network bandwidth can be reasonably

distributed and utilized.

Choose the menu QoS→Bandwidth Control→Rate Limit to load the following page.

Figure 11-10 Rate Limit

The following entries are displayed on this screen:

 Rate Limit Config

UNIT:1/LAGS:

Click 1 to configure the physical ports. Click LAGS to

configure the link aggregation groups.

Select:

Select the desired port for Rate configuration. It is

multi-optional.

Port:

Displays the port number of the switch.

229
