Create VLAN20 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a

VLAN with its VLAN ID as 20, owning Port 3 and Port 4.

 Configure switch B

Step

Operation

Description

Configure the

Link Type of the

ports

Required. On VLAN→802.1Q VLAN→Port Config page, configure

the link type of Port 7, Port 6 and Port 8 as ACCESS, TRUNK and

ACCESS respectively.

Create VLAN10 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a

VLAN with its VLAN ID as 10, owning Port 6 and Port 8.

Create VLAN20 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a

VLAN with its VLAN ID as 20, owning Port 6 and Port 7.

6.3 MAC VLAN

MAC VLAN technology is the way to classify VLANs according to the MAC addresses of Hosts.

A MAC address corresponds to a single VLAN ID. For the device in a MAC VLAN, if its MAC

address is bound to VLAN, the device can be connected to another member port in this VLAN

and still takes its member role effect without changing the configuration of VLAN members.

The packet in MAC VLAN is processed in the following way:

• When receiving an untagged packet, the switch matches the packet with the current

MAC VLAN. If the packet is matched, the switch will add a corresponding MAC VLAN tag

to it. If no MAC VLAN is matched, the switch will add a tag to the packet according to the

PVID of the received port. Thus, the packet is assigned automatically to the

corresponding VLAN for transmission.

• When receiving tagged packet, the switch will process it basing on the 802.1Q VLAN. If

the received port is the member of the VLAN to which the tagged packet belongs, the

packet will be forwarded normally. Otherwise, the packet will be discarded.

• If the MAC address of a Host is classified into 802.1Q VLAN, please set its connected

port of switch to be a member of this 802.1Q VLAN so as to ensure the packets

forwarded normally.

6.3.1 MAC VLAN

On this page, you can create MAC VLAN and view the current MAC VLANs in the table.
