Tp-Link T2600G-28MPS (TL-SG3424P) [249/379] Configuration procedure of voice vlan
![Tp-Link T2600G-28MPS (TL-SG3424P) [249/379] Configuration procedure of voice vlan](/views2/1210070/page249/bgf9.png)
Description:
Displays the description of the OUI.
Configuration Procedure of Voice VLAN:
Step
Operation
Description
1
Create VLAN Required. On VLAN→802.1Q VLAN→
VLAN Config
page, click the Create button to create a VLAN.
2
Add OUI address Optional. On QoS→Voice VLAN→OUI Config page, you
can check whether the switch is supporting the OUI
template or not. If not, please add the OUI address.
3
Configure the parameters
of the ports in voice
VLAN.
Required. On QoS→Voice VLAN→Port Config page,
configure the parameters of the ports in voice VLAN.
4
Enable Voice VLAN Required. On QoS→Voice VLAN→Global Config page,
configure the global parameters of voice VLAN.
Return to CONTENTS
237
