provide is limited, some attributes should be set to make full use of the power and guarantee

the adequate power to the linked PDs. When the power exceeds the maximum power limit or

the power is inadequate to power the device, the switch may disconnect the power supply to

the PD linked to the port with lower priority. When detecting a PD is unplugged, the switch will

stop supplying the power to the PD.

PoE Config, mainly for PoE attributes configuration, is implemented on PoE Config and PoE

Profile pages.

12.1.1 PoE Config

On this page, you can configure the parameters to implement PoE function.

Choose the menu PoE→PoE Config→PoE Config to load the following page.

Figure 12-1 PoE Config

The following items are displayed on this screen:



Global Config

System Power Limit: Defines the max power the PoE switch can supply.

It ranges

from 1W to 384W.

System Power

Consumption:

Displays the PoE switch's real time system power consumption.

System Power

Remain:

Displays the PoE switch's real time remaining system power.



Port Config

Select:

Select the desired port to configure its parameters.

Port:

Displays the port number.
