13.4.3 VLAN Binding

On this page you can bind an ACL to a VLAN.

Choose the menu ACL→ACL Binding→VLAN Binding to load the following page.

Figure 13-16 Bind the policy to the VLAN

The following entries are displayed on this screen:



VLAN-Bind Config

ACL ID:

Select the ID of the ACL you want to bind.

VLAN ID:

Enter the ID of the VLAN you want to bind.



VLAN-Bind Table

Index:

Displays the index of the binding ACL.

ACL ID:

Displays the ID of the binding ACL.

VLAN ID:

Displays the ID of the VLAN bound to the corresponding ACL.

Direction:

Displays the binding direction.

Configuration Procedure:

Step

Operation

Description

Configure ACL rules Required. On ACL→ACL Config

configuration pages,

configure ACL rules to match packets.

Bind the ACL

to the

port/VLAN

Required. On ACL→ACL Binding

configuration pages,

bind the ACL to the port/VLAN to make the ACL effective

on the corresponding port/VLAN.

13.5 Policy Binding

Policy Binding function can have the policy take its effect on a specific port/VLAN. The policy

will take effect only when it is bound to a port/VLAN. In the same way, the port/VLAN will

receive the data packets and process them based on the policy only when the policy is bound

to the port/VLAN.
