Chapter
Introduction
Chapter 6 VLAN This module is used to configure VLANs to control broadcast
in LANs. Here mainly introduces:
802.1Q VLAN: Configure port-based VLAN.
MAC VLAN: Configure MAC-based VLAN without changing
the 802.1Q VLAN configuration.
Protocol VLAN: Create VLANs in application layer to make
some special data transmitted in the specified VLAN.
VLAN VPN: VLAN VPN allows the packets with VLAN tags of
private networks to be encapsulated with VLAN tags of
public networks at the network access terminal of the
Internet Service Provider.
GVRP: GVRP allows the switch to automatically add or
remove the VLANs via the dynamic VLAN registration
information and propagate the local VLAN registration
information to other switches, without having to individually
configure each VLAN.
Private VLAN: Designed to save VLAN resources of uplink
devices and decrease broadcast. Private VLAN mainly used
in campus or enterprise networks to achieve user layer-2-
separation and to save VLAN resources of uplink devices.
Chapter 7 Spanning Tree This module is used to configure spanning tree function of the
switch. Here mainly introduces:
STP Config: Configure and view the global settings of
spanning tree function.
Port Config: Configure CIST parameters of ports.
MSTP Instance: Configure MSTP instances.
STP Securi
ty: Configure protection function to prevent
devices from any malicious attack against STP features.
Chapter 8 Ethernet OAM This module is used to configure Ethernet OAM function of the
switch. Here mainly introduces:
Ba
sic Config: Enable the Ethernet OAM function, configure
its OAM mode, and check out the connection status.
Link Monitoring: Configure the parameters about OAM link
events and choose whether to notify the link event.
RFI: Choose whether to notify the link faults like dying gasp
and critical event.
Remote Loopback: Start or stop the remote loopback;
choose to ignore or to process the received remote
loopback request.
Statistics: View the statistics about the detailed Ethernet
OAM traffic information and event log information.
DLDP: Configure the DLDP function to allow the switch to
monitor the physical configuration of the cables and detect
whether a unidirectional link exists.
4
